Name: Label Feeder(GS-HQ90)
Brand: Global Soul Limited
SKU: GS-HQ90
Availability: InStock

À la maison > produits > Chargeur CMS >

Label Feeder(GS-HQ90)

Place of Origin:

China

Nom de marque:

Model Number:

GS-HQ90

Nous contacter

Demandez un devis

Détails du produit

Model:

GS-HQ90

Overall dimensions (length * width * height):

930*130/72*390mm( There are two widths: 130mm and 72mm)

Weight:

13/9.5(The 130mm style weighs 13KG The 72mm style weighs 9.5KG)

Working voltage:

DC 24V

Gas source requirements:

Maximum current:

Feeding speed:

Adjustable at 35mm/s

Operation panel:

3.5-inch touchscreen

Feeding accuracy:

+0.3mm

Condition:

New

Conditions de paiement et d'expédition

Minimum Order Quantity

1/PCS

Prix

USD+negotiable+pcs

Packaging Details

1000*150*90

Delivery Time

1-3 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Produits connexes

8-Bit Power Box (GS-RAD2106-DY08)

Obtenez le meilleur prix

Le système d'alimentation à détecteur à double voie (GS-JAT2110) [à double voie]

Obtenez le meilleur prix

Nous contacter

86-0755-27678283

Contactez-nous maintenant

Description du produit

Label Feeder(GS-HQ90)

The label feeder is a component supply device that strips rolls of labels at certain intervals and at specified times one by one and supplies them to the surface mount technology (SMT) machine.

Label Feeder(GS-HQ90) 0

Label Feeder(GS-HQ90) 1

Tape description:
1. Tape width: The supported tape width is ≤85mm
2. The distance between the front, back, left and right of the materials should be 2 to 3mm. Leave a blank area of about 5mm on both sides of the material tape
3. The number of items in each row should be controlled within 6 (the more items there are in a row, the greater the chance of abnormality).
4. Suitable thickness of base paper: 0.05mm
